Title: | Genetic Algorithm for Wind Farm Layout Optimization |
Version: | 4.0.0 |
Maintainer: | Sebastian Gatscha <sebastian_gatscha@gmx.at> |
Description: | The genetic algorithm is designed to optimize wind farms of any shape. It requires a predefined amount of turbines, a unified rotor radius and an average wind speed value for each incoming wind direction. A terrain effect model can be included that downloads an 'SRTM' elevation model and loads a Corine Land Cover raster to approximate surface roughness. |
Depends: | R (≥ 4.1.0) |
Imports: | Rcpp, terra, sf, RColorBrewer, calibrate, grDevices, graphics, magrittr, methods, stats, utils |
LinkingTo: | Rcpp |
LazyData: | TRUE |
License: | MIT + file LICENSE |
URL: | https://ysosirius.github.io/windfarmGA/index.html |
BugReports: | https://github.com/YsoSirius/windfarmGA/issues |
Encoding: | UTF-8 |
RoxygenNote: | 7.3.2 |
Suggests: | testthat (≥ 3.0.0), foreach, parallel, doParallel, progress, stars, raster, leaflet, elevatr (≥ 0.99.0), ggplot2, gstat, rworldmap |
X-schema.org-keywords: | windfarm-layout, optimization, genetic-algorithm, renewable-energy, r, rstats, r-package |
Config/testthat/edition: | 3 |
Config/testthat/parallel: | true |
NeedsCompilation: | yes |
Packaged: | 2025-01-18 09:24:17 UTC; kona1 |
Author: | Sebastian Gatscha [aut, cre, cph] |
Repository: | CRAN |
Date/Publication: | 2025-01-18 11:00:02 UTC |
windfarmGA: Genetic Algorithm for Wind Farm Layout Optimization
Description
The genetic algorithm is designed to optimize wind farms of any shape. It requires a predefined amount of turbines, a unified rotor radius and an average wind speed value for each incoming wind direction. A terrain effect model can be included that downloads an 'SRTM' elevation model and loads a Corine Land Cover raster to approximate surface roughness.
Details
A package to optimize small wind farms with irregular shapes
using a genetic algorithm. It requires a fixed amount of turbines, a fixed
rotor radius and an average wind speed value for each incoming wind
direction. A terrain effect model can be included which downloads a digital
elevation model and a Corine Land Cover raster to approximate surface
roughness. Further information can be found at the description of the
function
genetic_algorithm
.
Author(s)
Maintainer: Sebastian Gatscha sebastian_gatscha@gmx.at
See Also
Useful links:
Calculates Air Density, Air Pressure and Temperature according to the Barometric Height Formula
Description
Calculates air density, temperature and air pressure respective to certain heights according to the International standard atmosphere and the barometric height formula.
Usage
barometric_height(data, height, po = 101325, ro = 1.225)
Arguments
data |
A data.frame containing the height values |
height |
Column name of the height values |
po |
Standardized air pressure at sea level (101325 Pa) |
ro |
Standardized air density at sea level (1,225 kg per m3) |
Value
Returns a data.frame with height values and corresponding air pressures, air densities and temperatures in Kelvin and Celsius.
See Also
Other Wind Energy Calculation Functions:
calculate_energy()
,
circle_intersection()
,
get_dist_angles()
,
turbine_influences()
Examples
data <- matrix(seq(0, 5000, 500))
barometric_height(data)
plot.ts(barometric_height(data))
A POLYGON with an area of ~70 km2
Description
A POLYGON with an area of ~70 km2
Usage
big_shape
Format
An object of class sf
(inherits from data.frame
) with 1 rows and 1 columns.
Calculate Energy Outputs of Individuals
Description
Calculate the energy output and efficiency rates of an individual in the current population under all given wind directions and speeds. If the terrain effect model is activated, the main calculations to model those effects will be done in this function.
Usage
calculate_energy(
sel,
referenceHeight,
RotorHeight,
SurfaceRoughness,
wnkl,
distanz,
polygon1,
RotorR,
dirSpeed,
srtm_crop,
topograp,
cclRaster,
weibull,
plotit = FALSE
)
Arguments
sel |
A matrix of an individual of the current population |
referenceHeight |
The height at which the incoming wind speeds were
measured. Default is |
RotorHeight |
The height of the turbine hub |
SurfaceRoughness |
A surface roughness length in meters.
With the terrain effect model, a surface roughness is calculated for every
grid cell using the elevation and land cover data. Default is |
wnkl |
The angle from which wake influences are considered to be negligible |
distanz |
The distance after which wake effects are considered to be eliminated |
polygon1 |
The considered area as Simple Feature Polygon |
RotorR |
The desired rotor radius in meter |
dirSpeed |
The wind speed and direction data.frame |
srtm_crop |
The first element of the |
topograp |
Boolean value, which indicates if the terrain effect model
should be enabled or not. Default is |
cclRaster |
The second element of the |
weibull |
A boolean value that specifies whether to take Weibull
parameters into account. If |
plotit |
If |
Value
Returns a list of an individual of the current generation with resulting wake effects, energy outputs, efficiency rates for every wind direction. The length of the list corresponds to the number of different wind directions.
See Also
Other Wind Energy Calculation Functions:
barometric_height()
,
circle_intersection()
,
get_dist_angles()
,
turbine_influences()
Examples
## Create a random Polygon
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Create a uniform and unidirectional wind data.frame and plot the
## resulting wind rose
data.in <- data.frame(ws = 12, wd = 0)
windrosePlot <- plot_windrose(
data = data.in, spd = data.in$ws,
dir = data.in$wd, dirres = 10, spdmax = 20
)
## Assign the rotor radius and a factor of the radius for grid spacing.
Rotor <- 50
fcrR <- 3
resGrid <- grid_area(
shape = Polygon1, size = Rotor * fcrR, prop = 1,
plotGrid = TRUE
)
## Assign the indexed data frame to new variable. Element 2 of the list
## is the grid, saved as Simple Feature Polygons.
resGrid1 <- resGrid[[1]]
## Create an initial population with the indexed Grid, 15 turbines and
## 100 individuals.
initpop <- init_population(Grid = resGrid1, n = 15, nStart = 100)
## Calculate the expected energy output of the first individual of the
## population.
par(mfrow = c(1, 2))
plot(Polygon1)
points(initpop[[1]][, "X"], initpop[[1]][, "Y"], pch = 20, cex = 2)
plot(resGrid[[2]], add = TRUE)
resCalcEn <- calculate_energy(
sel = initpop[[1]], referenceHeight = 50,
RotorHeight = 50, SurfaceRoughness = 0.14, wnkl = 20,
distanz = 100000, dirSpeed = data.in,
RotorR = 50, polygon1 = Polygon1, topograp = FALSE,
weibull = FALSE
)
resCalcEn <- as.data.frame(resCalcEn)
plot(Polygon1, main = resCalcEn[, "Energy_Output_Red"][[1]])
points(x = resCalcEn[, "Bx"], y = resCalcEn[, "By"], pch = 20)
## Create a variable and multidirectional wind data.frame and plot the
## resulting wind rose
data.in10 <- data.frame(ws = runif(10, 1, 25), wd = runif(10, 0, 360))
windrosePlot <- plot_windrose(
data = data.in10, spd = data.in10$ws,
dir = data.in10$wd, dirres = 10, spdmax = 20
)
## Calculate the energy outputs for the first individual with more than one
## wind direction.
resCalcEn <- calculate_energy(
sel = initpop[[1]], referenceHeight = 50,
RotorHeight = 50, SurfaceRoughness = 0.14, wnkl = 20,
distanz = 100000, dirSpeed = data.in10,
RotorR = 50, polygon1 = Polygon1, topograp = FALSE,
weibull = FALSE
)
Get area of intersecting circles
Description
Calculate the intersection area of two circles with different radii and different heights
Usage
circle_intersection(r1, r2, h1, h2, dx)
Arguments
r1 |
The radius of circle 1 |
r2 |
The radius of circle 2 |
h1 |
The height of the circle center 1 |
h2 |
The height of the circle center 2 |
dx |
The distance on the x-axis between both centers |
Value
A numeric value
See Also
Other Wind Energy Calculation Functions:
barometric_height()
,
calculate_energy()
,
get_dist_angles()
,
turbine_influences()
Crossover Method
Description
The crossover method creates new offspring with the selected individuals by permutating their genetic codes.
Usage
crossover(se6, u, uplimit, crossPart = c("EQU", "RAN"), verbose, seed)
Arguments
se6 |
The selected individuals. The output of |
u |
The crossover point rate |
uplimit |
The upper limit of allowed permutations |
crossPart |
The crossover method. Either "EQU" or "RAN" |
verbose |
If |
seed |
Set a seed for comparability. Default is |
Value
Returns a binary coded matrix of all permutations and all grid cells, where 0 indicates no turbine and 1 indicates a turbine in the grid cell.
See Also
Other Genetic Algorithm Functions:
fitness()
,
genetic_algorithm()
,
init_population()
,
mutation()
,
selection()
,
trimton()
Examples
## Create two random parents with an index and random binary values
Parents <- data.frame(
ID = 1:20,
bin = sample(c(0, 1), 20, replace = TRUE, prob = c(70, 30)),
bin.1 = sample(c(0, 1), 20, replace = TRUE, prob = c(30, 70))
)
## Create random Fitness values for both individuals
FitParents <- data.frame(ID = 1, Fitness = 1000, Fitness.1 = 20)
## Assign both values to a list
CrossSampl <- list(Parents, FitParents)
## Cross their data at equal locations with 2 crossover parts
crossover(CrossSampl, u = 1.1, uplimit = 300, crossPart = "EQU")
## with 3 crossover parts and equal locations
crossover(CrossSampl, u = 2.5, uplimit = 300, crossPart = "EQU")
## or with random locations and 5 crossover parts
crossover(CrossSampl, u = 4.9, uplimit = 300, crossPart = "RAN")
Evaluate the Individual Fitness values
Description
The fitness of all individuals in the current population
is calculated after their energy output has been evaluated in
calculate_energy
. This function reduces the resulting energy
outputs to a single fitness value for each individual.
Usage
fitness(
selection,
referenceHeight,
RotorHeight,
SurfaceRoughness,
Polygon,
resol1,
rot,
dirspeed,
srtm_crop,
topograp,
cclRaster,
weibull,
Parallel,
numCluster
)
Arguments
selection |
A list containing all individuals of the current population. |
referenceHeight |
The height at which the incoming wind speeds were
measured. Default is |
RotorHeight |
The height of the turbine hub |
SurfaceRoughness |
A surface roughness length in meters.
With the terrain effect model, a surface roughness is calculated for every
grid cell using the elevation and land cover data. Default is |
Polygon |
The considered area as shapefile. |
resol1 |
The resolution of the grid in meter. |
rot |
The desired rotor radius in meter. |
dirspeed |
The wind data as list. |
srtm_crop |
A list of 3 raster, with 1) the elevation, 2) an orographic
and 3) a terrain raster. Calculated in |
topograp |
Boolean value, which indicates if the terrain effect model
should be enabled or not. Default is |
cclRaster |
A Corine Land Cover raster, that has to be adapted previously by hand with the surface roughness length for every land cover type. Is only used, when the terrain effect model is activated. |
weibull |
A raster representing the estimated wind speeds |
Parallel |
A boolean value, indicating whether parallel processing
should be used. The parallel and doParallel packages are used for
parallel processing. Default is |
numCluster |
If |
Value
Returns a list with every individual, consisting of X & Y coordinates, rotor radii, the runs and the selected grid cell IDs, and the resulting energy outputs, efficiency rates and fitness values.
See Also
Other Genetic Algorithm Functions:
crossover()
,
genetic_algorithm()
,
init_population()
,
mutation()
,
selection()
,
trimton()
Examples
## Create a random rectangular shapefile
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Create a uniform and unidirectional wind data.frame and plots the
## resulting wind rose
## Uniform wind speed and single wind direction
wind <- data.frame(ws = 12, wd = 0)
# windrosePlot <- plot_windrose(data = wind, spd = wind$ws,
# dir = wind$wd, dirres=10, spdmax=20)
## Calculate a Grid and an indexed data.frame with coordinates and
## grid cell IDs.
Grid1 <- grid_area(shape = Polygon1, size = 200, prop = 1)
Grid <- Grid1[[1]]
AmountGrids <- nrow(Grid)
wind <- list(wind, probab = 100)
startsel <- init_population(Grid, 10, 20)
fit <- fitness(
selection = startsel, referenceHeight = 100, RotorHeight = 100,
SurfaceRoughness = 0.3, Polygon = Polygon1, resol1 = 200, rot = 20,
dirspeed = wind, srtm_crop = "", topograp = FALSE, cclRaster = "",
Parallel = FALSE
)
Run a Genetic Algorithm to optimize a wind farm layout
Description
Run a Genetic Algorithm to optimize the layout of wind turbines on a given area. The algorithm works with a fixed amount of turbines, a fixed rotor radius and a mean wind speed value for every incoming wind direction.
Usage
genetic_algorithm(
Polygon1,
GridMethod,
Rotor,
n,
fcrR,
referenceHeight,
RotorHeight,
SurfaceRoughness,
Proportionality,
iteration,
mutr,
vdirspe,
topograp,
elitism,
nelit,
selstate,
crossPart1,
trimForce,
Projection,
sourceCCL,
sourceCCLRoughness,
weibull,
weibullsrc,
Parallel,
numCluster,
verbose = FALSE,
plotit = FALSE
)
Arguments
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
GridMethod |
Should the polygon be divided into rectangular or hexagonal
grid cells? The default is |
Rotor |
The rotor radius in meter |
n |
The amount of turbines |
fcrR |
A numeric value used for grid spacing. Default is |
referenceHeight |
The height at which the incoming wind speeds were
measured. Default is |
RotorHeight |
The height of the turbine hub |
SurfaceRoughness |
A surface roughness length in meters.
With the terrain effect model, a surface roughness is calculated for every
grid cell using the elevation and land cover data. Default is |
Proportionality |
A numeric value used for the grid calculation, as it
determines the percentage a grid cell must overlay the area.
Default is |
iteration |
The number of iterations. Default is |
mutr |
A numeric mutation rate. Default is |
vdirspe |
A data.frame containing the wind speeds, directions and
probabilities. See |
topograp |
Boolean value, which indicates if the terrain effect model
should be enabled or not. Default is |
elitism |
Boolean value, which indicates whether elitism should be
activated or not. Default is |
nelit |
If |
selstate |
Determines which selection method is used, "FIX" selects a constant percentage and "VAR" selects a variable percentage, depending on the development of the fitness values. Default is "FIX" |
crossPart1 |
Determines which crossover method is used, "EQU" divides
the genetic code at equal intervals and "RAN" divides the genetic code at
random locations. Default is |
trimForce |
If |
Projection |
A spatial reference system. Depending on your PROJ-version,
it should either be a numeric |
sourceCCL |
The path to the Corine Land Cover raster (.tif). Only required when the terrain effect model is activated. |
sourceCCLRoughness |
The source to the adapted Corine Land Cover legend as .csv file. Only required when terrain effect model is activated. As default a .csv file within this package (‘~/extdata’) is taken that was already adapted manually. |
weibull |
A boolean value that specifies whether to take Weibull
parameters into account. If |
weibullsrc |
A list of Weibull parameter rasters, where the first list
item must be the shape parameter raster |
Parallel |
A boolean value, indicating whether parallel processing
should be used. The parallel and doParallel packages are used for
parallel processing. Default is |
numCluster |
If |
verbose |
If TRUE it will print information for every generation.
Default is |
plotit |
If TRUE it will plot the best windfarm of every generation.
Default is |
Details
A terrain effect model can be included in the optimization process.
Therefore, a digital elevation model will be downloaded automatically via
the elevatr::get_elev_raster
function. A land cover raster can also
downloaded automatically from the EEA-website, or the path to a raster file
can be passed to sourceCCL
. The algorithm uses an adapted version of
the Raster legend ("clc_legend.csv"), which is stored in the package
directory ‘~/inst/extdata’. To use other values for the land cover
roughness lengths, insert a column named "Rauhigkeit_z" to the
.csv file, assign a surface roughness length to all land cover types. Be
sure that all rows are filled with numeric values and save the file with
";" separation. Assign the path of the file to the input variable
sourceCCLRoughness
of this function.
Value
The result is a matrix with aggregated values per generation; the best individual regarding energy and efficiency per generation, some fuzzy control variables per generation, a list of all fitness values per generation, the amount of individuals after each process, a matrix of all energy, efficiency and fitness values per generation, the selection and crossover parameters, a matrix with the generational difference in maximum and mean energy output, a matrix with the given inputs, a dataframe with the wind information, the mutation rate per generation and a matrix with all tested wind farm layouts.
See Also
Other Genetic Algorithm Functions:
crossover()
,
fitness()
,
init_population()
,
mutation()
,
selection()
,
trimton()
Examples
## Not run:
## Create a random rectangular shapefile
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Create a uniform and unidirectional wind data.frame and plot the
## resulting wind rose
data.in <- data.frame(ws = 12, wd = 0)
windrosePlot <- plot_windrose(
data = data.in, spd = data.in$ws,
dir = data.in$wd, dirres = 10, spdmax = 20
)
## Runs an optimization run for 20 iterations with the
## given shapefile (Polygon1), the wind data.frame (data.in),
## 12 turbines (n) with rotor radii of 30m (Rotor) and rotor height of 100m.
result <- genetic_algorithm(
Polygon1 = Polygon1,
n = 12,
vdirspe = data.in,
Rotor = 30,
RotorHeight = 100
)
plot_windfarmGA(result = result, Polygon1 = Polygon1)
## End(Not run)
Calculate distances and angles of possibly influencing turbines
Description
Calculate distances and angles for a turbine and all it's potentially influencing turbines.
Usage
get_dist_angles(t, o, wnkl, dist, polYgon, plotAngles = FALSE)
Arguments
t |
A data.frame of the current individual with X and Y coordinates |
o |
A numeric value indicating the index of the current turbine |
wnkl |
The angle from which wake influences are considered to be negligible |
dist |
A numeric value indicating the distance, after which the wake effects are considered to be eliminated. |
polYgon |
A shapefile representing the considered area |
plotAngles |
A logical variable, which is used to plot the distances and
angles. Default is |
Value
Returns a matrix with the distances, angles and heights of potentially influencing turbines
See Also
Other Wind Energy Calculation Functions:
barometric_height()
,
calculate_energy()
,
circle_intersection()
,
turbine_influences()
Examples
library(sf)
## Exemplary input Polygon with 2km x 2km:
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Create a random windfarm with 10 turbines
t <- st_coordinates(st_sample(Polygon1, 10))
t <- cbind(t, "Z" = 1)
wnkl <- 20
dist <- 100000
## Evaluate and plot for every turbine all other potentially influencing turbines
potInfTur <- list()
for (i in 1:(length(t[, 1]))) {
potInfTur[[i]] <- get_dist_angles(
t = t, o = i, wnkl = wnkl,
dist = dist, polYgon = Polygon1, plotAngles = TRUE
)
}
potInfTur
Get the Grid-IDs from binary matrix
Description
Retrieve the grid ID's from the binary matrix, where the binary code indicates which grid cells are used in the current wind farm constellation.
Usage
get_grids(trimtonOut, Grid)
Arguments
trimtonOut |
Input matrix with binary values |
Grid |
Grid of the considered area |
Value
Returns a list of all individuals with X and Y coordinates and the grid cell ID.
See Also
Other Helper Functions:
grid_area()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
readintegerSel()
,
splitAt()
,
windata_format()
Examples
## Create a random rectangular shapefile
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(0, 0, 2000, 2000, 0),
c(0, 2000, 2000, 0, 0)
))),
crs = 3035
))
## Calculate a Grid and an indexed data.frame with coordinates and
## grid cell Ids.
Grid1 <- grid_area(shape = Polygon1, size = 200, prop = 1)
Grid <- Grid1[[1]]
AmountGrids <- nrow(Grid)
startsel <- init_population(Grid, 10, 20)
wind <- data.frame(ws = 12, wd = 0)
wind <- list(wind, probab = 100)
fit <- fitness(
selection = startsel, referenceHeight = 100, RotorHeight = 100,
SurfaceRoughness = 0.3, Polygon = Polygon1, resol1 = 200, rot = 20,
dirspeed = wind, srtm_crop = "", topograp = FALSE, cclRaster = ""
)
allparks <- do.call("rbind", fit)
## SELECTION
## print the amount of Individuals selected.
## Check if the amount of Turbines is as requested.
selec6best <- selection(fit, Grid, 2, TRUE, 6, "VAR")
## CROSSOVER
## u determines the amount of crossover points,
## crossPart determines the method used (Equal/Random),
## uplimit is the maximum allowed permutations
crossOut <- crossover(selec6best, 2, uplimit = 300, crossPart = "RAN")
## MUTATION
## Variable Mutation Rate is activated if more than 2 individuals represent
## the current best solution.
mut <- mutation(a = crossOut, p = 0.3)
## TRIMTON
## After Crossover and Mutation, the amount of turbines in a windpark change
## and have to be corrected to the required amount of turbines.
mut1 <- trimton(
mut = mut, nturb = 10, allparks = allparks,
nGrids = AmountGrids, trimForce = FALSE
)
## Get the new Grid-Ids and run a new fitness run.
getRectV <- get_grids(mut1, Grid)
fit <- fitness(
selection = getRectV, referenceHeight = 100, RotorHeight = 100,
SurfaceRoughness = 0.3, Polygon = Polygon1, resol1 = 200, rot = 20,
dirspeed = wind, srtm_crop = "", topograp = FALSE, cclRaster = ""
)
head(fit)
Make a grid from a Simple Feature Polygon
Description
Create a grid from a given polygon with a certain resolution and proportionality. The grid cell centroids represent possible wind turbine locations.
Usage
grid_area(shape, size = 500, prop = 1, plotGrid = FALSE)
Arguments
shape |
Simple Feature Polygon of the considered area |
size |
The cellsize of the grid in meters. Default is 500 |
prop |
A factor used for grid calculation. It determines the minimum percentage that a grid cell must cover the area. Default is 1 |
plotGrid |
Logical value indicating whether the results should be
plotted. Default is |
Value
Returns a list with 2 elements. List element 1 will have the grid cell IDS, and the X and Y coordinates of the centers of each grid cell. List element 2 is the grid as Simple Feature Polygons, which is used for plotting purposes.
Note
The grid of the genetic algorithm will have a resolution of Rotor
* fcrR
. See the arguments of genetic_algorithm
See Also
Other Helper Functions:
get_grids()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
readintegerSel()
,
splitAt()
,
windata_format()
Examples
## Exemplary input Polygon with 2km x 2km:
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(0, 0, 2000, 2000, 0),
c(0, 2000, 2000, 0, 0)
))),
crs = 3035
))
## Create a Grid
grid_area(Polygon1, 200, 1, TRUE)
grid_area(Polygon1, 400, 1, TRUE)
## Examplary irregular input Polygon
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(0, 0, 2000, 3000, 0),
c(20, 200, 2000, 0, 20)
))),
crs = 3035
))
## Create a Grid
grid_area(Polygon1, 200, 1, TRUE)
grid_area(Polygon1, 200, 0.1, TRUE)
grid_area(Polygon1, 400, 1, TRUE)
grid_area(Polygon1, 400, 0.1, TRUE)
Polygon to Hexagonal Grids
Description
The function takes a Simple Feature Polygon and a size argument and creates a list with an indexed matrix with coordinates and a Simple Feature object, that consists of hexagonal grids.
Usage
hexa_area(shape, size = 500, plotGrid = FALSE)
Arguments
shape |
Simple Feature Polygon of the considered area |
size |
The cellsize of the grid in meters. Default is 500 |
plotGrid |
Logical value indicating whether the results should be
plotted. Default is |
Value
Returns a list with 2 elements. List element 1 will have the grid cell IDS, and the X and Y coordinates of the centers of each grid cell. List element 2 is the grid as Simple Feature Polygons, which is used for plotting purposes.
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
readintegerSel()
,
splitAt()
,
windata_format()
Examples
library(sf)
## Exemplary input Polygon with 2km x 2km:
Poly <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
HexGrid <- hexa_area(Poly, 100, TRUE)
A POLYGON with a hole
Description
A POLYGON with a hole
Usage
hole_shape
Format
An object of class sf
(inherits from data.frame
) with 1 rows and 2 columns.
Create a random initial Population
Description
Create nStart
random sub-selections from the indexed
grid and assign binary variable 1 to selected grids. This function
initiates the genetic algorithm with a first random population and will
only be needed in the first iteration.
Usage
init_population(Grid, n, nStart = 100)
Arguments
Grid |
The data.frame output of |
n |
A numeric value indicating the amount of required turbines. |
nStart |
A numeric indicating the amount of randomly generated initial individuals. Default is 100. |
Value
Returns a list of nStart
initial individuals, each consisting
of n
turbines. Resulting list has the x and y coordinates, the grid
cell ID and a binary variable of 1, indicating a turbine in the grid cell.
See Also
Other Genetic Algorithm Functions:
crossover()
,
fitness()
,
genetic_algorithm()
,
mutation()
,
selection()
,
trimton()
Examples
library(sf)
## Exemplary input Polygon with 2km x 2km:
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
Grid <- grid_area(Polygon1, 200, 1, TRUE)
## Create 5 individuals with 10 wind turbines each.
firstPop <- init_population(Grid = Grid[[1]], n = 10, nStart = 5)
Transform to Simple Feature Polygons
Description
Helper Function, which transforms SpatialPolygons or coordinates in matrix/data.frame - form to a Simple Feature Polygon
Usage
isSpatial(shape, proj)
Arguments
shape |
An area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
proj |
Which Projection should be assigned to matrix / data.frame coordinates |
Details
If the columns are named, it will look for common abbreviation to match x/y or long/lat columns. If the columns are not named, the first 2 numeric columns are taken.
Value
A Simple Feature Polygon
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
permutations()
,
readinteger()
,
readintegerSel()
,
splitAt()
,
windata_format()
Examples
library(sf)
df <- rbind(
c(4498482, 2668272), c(4498482, 2669343),
c(4499991, 2669343), c(4499991, 2668272)
)
isSpatial(df)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
isSpatial(st_coordinates(Polygon1), 3035)
A MULTIPOLYGON with 3 Polygons
Description
A MULTIPOLYGON with 3 Polygons
Usage
multi_shape
Format
An object of class sf
(inherits from data.frame
) with 1 rows and 1 columns.
Mutation Method
Description
The function randomly mutates an individual's genetic code
Usage
mutation(a, p, seed = NULL)
Arguments
a |
The binary matrix of all individuals |
p |
The mutation rate |
seed |
Set a seed for comparability. Default is |
Value
Returns a binary matrix with mutated genes.
See Also
Other Genetic Algorithm Functions:
crossover()
,
fitness()
,
genetic_algorithm()
,
init_population()
,
selection()
,
trimton()
Examples
## Create 4 random individuals with binary values
a <- cbind(
bin0 = sample(c(0, 1), 20, replace = TRUE, prob = c(70, 30)),
bin1 = sample(c(0, 1), 20, replace = TRUE, prob = c(30, 70)),
bin2 = sample(c(0, 1), 20, replace = TRUE, prob = c(30, 70)),
bin3 = sample(c(0, 1), 20, replace = TRUE, prob = c(30, 70))
)
a
## Mutate the individuals with a low percentage
aMut <- mutation(a, 0.1, NULL)
## Check which values are not like the originals
a == aMut
## Mutate the individuals with a high percentage
aMut <- mutation(a, 0.4, NULL)
## Check which values are not like the originals
a == aMut
Is the package installed or not
Description
Is the package installed or not
Usage
is_foreach_installed()
is_parallel_installed()
is_doparallel_installed()
is_ggplot2_installed()
is_leaflet_installed()
is_elevatr_installed()
Value
An invisible boolean value, indicating if the package is installed or not.
Enumerate the Combinations or Permutations of the Elements of a Vector
Description
permutations enumerates the possible permutations. The function is forked and minified from gtools::permutations
Usage
permutations(n, r, v = 1:n)
Arguments
n |
Size of the source vector |
r |
Size of the target vectors |
v |
Source vector. Defaults to 1:n |
Value
Returns a matrix where each row contains a vector of length r.
Author(s)
Original versions by Bill Venables. Extended to handle repeats.allowed by Gregory R. Warnes
References
Venables, Bill. "Programmers Note", R-News, Vol 1/1, Jan. 2001. https://cran.r-project.org/doc/Rnews/
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
isSpatial()
,
readinteger()
,
readintegerSel()
,
splitAt()
,
windata_format()
Plot outputs of all generations with standard deviations
Description
Plot the fitness, efficiency and energy outputs of all generations and the corresponding standard deviations.
Usage
plot_cloud(result, pl = FALSE)
Arguments
result |
The output of |
pl |
Should the results be plotted? Default is FALSE |
Value
Returns a data.frame with the values for fitness, efficiency and energy for all evaluated individuals
See Also
Other Plotting Functions:
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
## Plot the results of a hexagonal grid optimization
plcdf <- plot_cloud(resulthex, TRUE)
Plot the progress of populations
Description
Plot the changes in mean and max fitness values to previous generation.
Usage
plot_development(result)
Arguments
result |
The output of |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
plot_development(resultrect)
Plot the evolution of fitness values
Description
Plot the evolution of energy outputs and efficiency rates over the whole generations. Plots min, mean and max values.
Usage
plot_evolution(result, ask = TRUE, spar = 0.1)
Arguments
result |
The output of |
ask |
Should R wait for interaction for subsequent plotting. Default is TRUE |
spar |
A numeric value determining how exact a spline should be drawn. Default is 0.1 |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
## Plot the results of a rectangular grid optimization
plot_evolution(resultrect, ask = TRUE, spar = 0.1)
Plot the changes of min/mean/max fitness values
Description
Plot the evolution of fitness values and the change in the min, mean and max fitness values to the former generations.
Usage
plot_fitness_evolution(result, spar = 0.1)
Arguments
result |
The output of |
spar |
A numeric value determining how exact a spline should be drawn. Default is 0.1 |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
## Plot the results of a hexagonal grid optimization
plot_fitness_evolution(resulthex, 0.1)
Plot a wind warm with leaflet
Description
Plot a resulting wind farm on a leaflet map.
Usage
plot_leaflet(result, Polygon1, which = 1, orderitems = TRUE, GridPol)
Arguments
result |
The output of |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
which |
A numeric value, indicating which individual to plot. The
default is 1. Combined with |
orderitems |
A logical value indicating whether the results should be
ordered by energy values |
GridPol |
By default, the grid will be calculated based on the inputs
of |
Value
Returns a leaflet map.
Examples
## Not run:
## Plot the best wind farm on a leaflet map (ordered by energy values)
plot_leaflet(result = resulthex, Polygon1 = sp_polygon, which = 1)
## Plot the last wind farm (ordered by chronology).
plot_leaflet(
result = resulthex, Polygon1 = sp_polygon, orderitems = FALSE,
which = 1
)
## Plot the best wind farm on a leaflet map with the rectangular Grid
Grid <- grid_area(sp_polygon, size = 150, prop = 0.4)
plot_leaflet(
result = resultrect, Polygon1 = sp_polygon, which = 1,
GridPol = Grid[[2]]
)
## Plot the last wind farm with hexagonal Grid
Grid <- hexa_area(sp_polygon, size = 75)
plot_leaflet(
result = resulthex, Polygon1 = sp_polygon, which = 1,
GridPol = Grid[[2]]
)
## End(Not run)
Plot the genetic algorithm results
Description
Plot the evolution of fitness values with the influences of selection, crossover and mutation.
Usage
plot_parkfitness(result, spar = 0.1)
Arguments
result |
The output of |
spar |
A numeric value determining how exact a spline should be drawn. Default is 0.1 |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
## Plot the results of a hexagonal grid optimization
plot_parkfitness(resulthex)
Plot the result of a randomized output.
Description
Plotting method for the results of
random_search_single
and random_search
.
Usage
plot_random_search(resultRS, result, Polygon1, best)
Arguments
resultRS |
The result of the random functions
|
result |
The output of |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
best |
How many best candidates to plot. Default is 1. |
Value
Returns NULL. Used for plotting
See Also
Other Randomization:
random_search()
,
random_search_single()
Examples
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
Res <- random_search(result = resultrect, Polygon1 = Polygon1)
plot_random_search(resultRS = Res, result = resultrect, Polygon1 = Polygon1, best = 2)
Plot the best results
Description
Plot the best solutions of the genetic algorithm.
Depending on plotEn
, either the best energy or efficiency solutions
can be plotted. best
indicates the amount of best solutions to plot.
Usage
plot_result(
result,
Polygon1,
best = 3,
plotEn = 1,
topographie = FALSE,
Grid = TRUE,
sourceCCLRoughness = NULL,
sourceCCL = NULL,
weibullsrc
)
Arguments
result |
The output of |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
best |
A numeric value indicating how many of the best individuals should be plotted |
plotEn |
A numeric value that indicates if the best energy or efficiency
output should be plotted. |
topographie |
A logical value, indicating whether terrain effects should be considered and plotted or not |
Grid |
If |
sourceCCLRoughness |
The source to the adapted Corine Land Cover legend as .csv file. Only required when terrain effect model is activated. As default a .csv file within this package (‘~/extdata’) is taken that was already adapted manually. |
sourceCCL |
The path to the Corine Land Cover raster (.tif). Only required when the terrain effect model is activated. |
weibullsrc |
A list of Weibull parameter rasters, where the first list
item must be the shape parameter raster |
Value
Returns a data.frame of the best (energy/efficiency) individual during all iterations
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_windfarmGA()
,
plot_windrose()
,
random_search_single()
Examples
## Not run:
## Add some data examples from the package
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Plot the results of a hexagonal grid optimization
plot_result(resulthex, Polygon1, best = 1, plotEn = 1, topographie = FALSE)
## Plot the results of a rectangular grid optimization
plot_result(resultrect, Polygon1, best = 1, plotEn = 1, topographie = FALSE)
## End(Not run)
Plot visibility
Description
Calculate and plot visibility for given points in a given area.
Usage
plot_viewshed(r, turbine_locs, h1 = 0, h2 = 0, plot = TRUE, ...)
Arguments
r |
The elevation SpatRaster |
turbine_locs |
Coordinates, SpatialPoint or SimpleFeature Points representing the wind turbines |
h1 |
A single number or numeric vector giving the extra height offsets
for the |
h2 |
The height offset for Point 2 |
plot |
Should the result be plotted. Default is |
... |
forwarded to |
Value
A mosaiced SpatRaster, representing the visibility for all turbine_locs
Examples
library(sf)
library(terra)
f <- system.file("ex/elev.tif", package = "terra")
r <- rast(f)
x <- project(r, "EPSG:2169")
shape <- sf::st_as_sf(as.polygons(terra::boundaries(x)))
plot(shape)
st_crs(shape) <- 2169
locs <- st_sample(shape, 10, type = "random")
plot_viewshed(x, locs, h1 = 0, h2 = 0, plot = TRUE)
Plot the results of an optimization run
Description
Plot the results of a genetic algorithm run with given inputs. Several plots try to show all relevant effects and outcomes of the algorithm. 6 plot methods are available that can be selected individually.
Usage
plot_windfarmGA(
result,
Polygon1,
whichPl = "all",
best = 1,
plotEn = 1,
weibullsrc
)
Arguments
result |
The output of |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
whichPl |
Which plots should be shown: 1-6 are possible. The default is "all" which shows all available plots |
best |
A numeric value indicating how many of the best individuals should be plotted |
plotEn |
A numeric value that indicates if the best energy or efficiency
output should be plotted. |
weibullsrc |
A list of Weibull parameter rasters, where the first list
item must be the shape parameter raster |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windrose()
,
random_search_single()
Examples
## Not run:
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Plot the results of a hexagonal grid optimization
plot_windfarmGA(resulthex, Polygon1, whichPl = "all", best = 1, plotEn = 1)
## Plot the results of a rectangular grid optimization
plot_windfarmGA(resultrect, Polygon1, whichPl = "all", best = 1, plotEn = 1)
## End(Not run)
Plot a Windrose
Description
Plot a wind rose of the wind data frame.
Usage
plot_windrose(
data,
spd,
dir,
spdres = 2,
dirres = 10,
spdmin = 1,
spdmax = 30,
palette = "YlGnBu",
spdseq = NULL,
plotit = TRUE
)
Arguments
data |
A data.frame containing the wind information |
spd |
The column of the wind speeds in "data" |
dir |
The column of the wind directions in "data" |
spdres |
The increment of the wind speed legend. Default is 2 |
dirres |
The size of the wind sectors. Default is 10 |
spdmin |
Minimum wind speed. Default is 1 |
spdmax |
Maximal wind speed. Default is 30 |
palette |
A color palette used for drawing the wind rose |
spdseq |
A wind speed sequence, that is used for plotting |
plotit |
Should the windrose be plotted? Default is TRUE |
Value
Returns NULL. Used for plotting
See Also
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
random_search_single()
Examples
## Exemplary Input Wind speed and direction data frame
# Uniform wind speed and single wind direction
data.in <- data.frame(ws = 12, wd = 0)
windrosePlot <- plot_windrose(
data = data.in, spd = data.in$ws,
dir = data.in$wd
)
# Random wind speeds and random wind directions
data.in <- data.frame(
ws = sample(1:25, 10),
wd = sample(1:260, 10)
)
windrosePlot <- plot_windrose(
data = data.in, spd = data.in$ws,
dir = data.in$wd
)
Randomize the output of the Genetic Algorithm
Description
Perform a random search in the grid cells, to further optimize the output of the wind farm layout.
Usage
random_search(result, Polygon1, n = 20, best = 1, Plot = FALSE, max_dist = 2.2)
Arguments
result |
The resulting matrix of the function |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
n |
The number of random searches to be performed. Default is 20. |
best |
Which best individuals should be the starting conditions for a random search. The default is 1. |
Plot |
Should the random search be plotted? Default is |
max_dist |
A numeric value multiplied by the rotor radius to perform
collision checks. Default is |
Value
Returns a list.
See Also
Other Randomization:
plot_random_search()
,
random_search_single()
Examples
new <- random_search(resultrect, sp_polygon, n = 20, best = 4)
plot_random_search(resultRS = new, result = resultrect, Polygon1 = sp_polygon, best = 2)
Randomize the location of a single turbine
Description
Perform a random search for a single turbine, to further optimize the output of the wind farm layout.
Usage
random_search_single(result, Polygon1, n = 20, Plot = FALSE, max_dist = 2.2)
Arguments
result |
The resulting matrix of the function |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
n |
The number of random searches to be performed. Default is 20. |
Plot |
Should the random search be plotted? Default is |
max_dist |
A numeric value multiplied by the rotor radius to perform collision checks. Default is 2.2 |
Value
Returns a list
See Also
Other Randomization:
plot_random_search()
,
random_search()
Other Plotting Functions:
plot_cloud()
,
plot_development()
,
plot_evolution()
,
plot_fitness_evolution()
,
plot_parkfitness()
,
plot_result()
,
plot_windfarmGA()
,
plot_windrose()
Check Input Crossover Method
Description
Checks whether the input for crossover
is given
correctly. If not, a message is prompted which asks to input one of the 2
available crossover methods. The available inputs are "E" and "R". "E"
refers to partitioning at equal intervals and "R" refers to random
partitioning.
Usage
readinteger()
Value
Returns the selected crossover method (character)
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readintegerSel()
,
splitAt()
,
windata_format()
Check Input Selection Method
Description
Checks whether the input for selection
is given
correctly. If not, a message is prompted which asks to input one of the 2
available selection methods. The available inputs are "F" and "V". "F"
refers to a fixed percentage of 50% and "V" refers to a variable
percentage, based on the development of the population fitness values.
Usage
readintegerSel()
Value
Returns the selected selection method (character)
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
splitAt()
,
windata_format()
A resulting matrix of genetic_algorithm
with 10 iterations
and a hexagonal grid derived from sp_polygon
Description
A resulting matrix of genetic_algorithm
with 10 iterations
and a hexagonal grid derived from sp_polygon
Usage
resulthex
Format
An object of class matrix
(inherits from array
) with 10 rows and 13 columns.
A resulting matrix of genetic_algorithm
with 200 iterations
and a rectangular grid derived from sp_polygon
Description
A resulting matrix of genetic_algorithm
with 200 iterations
and a rectangular grid derived from sp_polygon
Usage
resultrect
Format
An object of class matrix
(inherits from array
) with 200 rows and 13 columns.
Selection Method
Description
Select a certain amount of individuals and recombine them to
parental teams. Add the mean fitness value of both parents to the parental
team. Depending on the selected selstate
, the algorithm will either
take always 50 percent or a variable percentage of the current population.
The variable percentage depends on the evolution of the populations fitness
values.
Usage
selection(fit, Grid, teil, elitism, nelit, selstate, verbose)
Arguments
fit |
A list of all fitness-evaluated individuals |
Grid |
Is the indexed grid output from |
teil |
A numeric value that determines the selection percentage |
elitism |
Boolean value, which indicates whether elitism should be
activated or not. Default is |
nelit |
If |
selstate |
Determines which selection method is used, "FIX" selects a constant percentage and "VAR" selects a variable percentage, depending on the development of the fitness values. Default is "FIX" |
verbose |
If TRUE, will print out further information. |
Value
Returns list with 2 elements. Element 1 is the binary encoded matrix which shows all selected individuals. Element 2 represent the mean fitness values of each parental team.
See Also
Other Genetic Algorithm Functions:
crossover()
,
fitness()
,
genetic_algorithm()
,
init_population()
,
mutation()
,
trimton()
Examples
## Exemplary input Polygon with 2km x 2km:
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4498482, 4498482, 4499991, 4499991, 4498482),
c(2668272, 2669343, 2669343, 2668272, 2668272)
))),
crs = 3035
))
## Calculate a Grid and an indexed data.frame with coordinates and grid cell Ids.
Grid1 <- grid_area(shape = Polygon1, size = 200, prop = 1)
Grid <- Grid1[[1]]
AmountGrids <- nrow(Grid)
startsel <- init_population(Grid, 10, 20)
wind <- as.data.frame(cbind(ws = 12, wd = 0))
wind <- list(wind, probab = 100)
fit <- fitness(
selection = startsel, referenceHeight = 100, RotorHeight = 100,
SurfaceRoughness = 0.3, Polygon = Polygon1, resol1 = 200,
rot = 20, dirspeed = wind,
srtm_crop = "", topograp = FALSE, cclRaster = ""
)
allparks <- do.call("rbind", fit)
## SELECTION
## print the amount of Individuals selected. Check if the amount
## of Turbines is as requested.
selec6best <- selection(fit, Grid, 2, TRUE, 6, "VAR")
selec6best <- selection(fit, Grid, 2, TRUE, 6, "FIX")
selec6best <- selection(fit, Grid, 4, FALSE, 6, "FIX")
The rectangular POLYGON used to create resultrect
& resulthex
Description
The rectangular POLYGON used to create resultrect
& resulthex
Usage
sp_polygon
Format
An object of class sf
(inherits from data.frame
) with 1 rows and 1 columns.
Split matrices or numeric vectors at specific indices
Description
The function is used by the crossover method to
split a genetic code at certain intervals. See also crossover
.
Usage
splitAt(x, pos)
Arguments
x |
A numeric variable that represents an individual's binary genetic code |
pos |
A numeric value that indicates where to split the genetic code |
Value
Returns a list of the split genetic code.
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
readintegerSel()
,
windata_format()
Examples
splitAt(1:100, 20)
splitAt(as.matrix(1:100), 20)
Get topographic rasters
Description
Calculate the SpatRasters needed for the terrain model.
Usage
terrain_model(
topograp = TRUE,
Polygon1,
sourceCCL,
sourceCCLRoughness,
plotit = FALSE,
verbose = FALSE
)
Arguments
topograp |
Boolean value, which indicates if the terrain effect model
should be enabled or not. Default is |
Polygon1 |
The considered area as SpatialPolygon, SimpleFeature Polygon or coordinates as matrix/data.frame |
sourceCCL |
The path to the Corine Land Cover raster (.tif). Only required when the terrain effect model is activated. |
sourceCCLRoughness |
The source to the adapted Corine Land Cover legend as .csv file. Only required when terrain effect model is activated. As default a .csv file within this package (‘~/extdata’) is taken that was already adapted manually. |
plotit |
Plots the elevation data |
verbose |
If TRUE it will print information for every generation.
Default is |
Value
A list of SpatRasters
Examples
## Not run:
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(4651704, 4651704, 4654475, 4654475, 4651704),
c(2692925, 2694746, 2694746, 2692925, 2692925)
))),
crs = 3035
))
Polygon_wgs84 <- sf::st_transform(Polygon1, st_crs(4326))
srtm <- elevatr::get_elev_raster(locations = Polygon_wgs84, z = 11)
res <- terrain_model(srtm, Polygon1)
## End(Not run)
Adjust the amount of turbines per windfarm
Description
Adjust the mutated individuals to the required amount of turbines.
Usage
trimton(mut, nturb, allparks, nGrids, trimForce, seed)
Arguments
mut |
A binary matrix with the mutated individuals |
nturb |
A numeric value indicating the amount of required turbines |
allparks |
A data.frame consisting of all individuals of the current generation |
nGrids |
A numeric value indicating the total amount of grid cells |
trimForce |
If |
seed |
Set a seed for comparability. Default is NULL |
Value
Returns a binary matrix with the correct amount of turbines per individual
See Also
Other Genetic Algorithm Functions:
crossover()
,
fitness()
,
genetic_algorithm()
,
init_population()
,
mutation()
,
selection()
Examples
## Create a random rectangular shapefile
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(0, 0, 2000, 2000, 0),
c(0, 2000, 2000, 0, 0)
))),
crs = 3035
))
## Create a uniform and unidirectional wind data.frame and plots the
## resulting wind rose
## Uniform wind speed and single wind direction
data.in <- as.data.frame(cbind(ws = 12, wd = 0))
## Calculate a Grid and an indexed data.frame with coordinates and grid cell Ids.
Grid1 <- grid_area(shape = Polygon1, size = 200, prop = 1)
Grid <- Grid1[[1]]
AmountGrids <- nrow(Grid)
startsel <- init_population(Grid, 10, 20)
wind <- as.data.frame(cbind(ws = 12, wd = 0))
wind <- list(wind, probab = 100)
fit <- fitness(
selection = startsel, referenceHeight = 100, RotorHeight = 100,
SurfaceRoughness = 0.3, Polygon = Polygon1, resol1 = 200, rot = 20,
dirspeed = wind, srtm_crop = "", topograp = FALSE, cclRaster = ""
)
allparks <- do.call("rbind", fit)
## SELECTION
## print the amount of Individuals selected.
## Check if the amount of Turbines is as requested.
selec6best <- selection(fit, Grid, 2, TRUE, 6, "VAR")
selec6best <- selection(fit, Grid, 2, TRUE, 6, "FIX")
selec6best <- selection(fit, Grid, 4, FALSE, 6, "FIX")
## CROSSOVER
## u determines the amount of crossover points,
## crossPart determines the method used (Equal/Random),
## uplimit is the maximum allowed permutations
crossOut <- crossover(selec6best, 2, uplimit = 300, crossPart = "RAN")
crossOut <- crossover(selec6best, 7, uplimit = 500, crossPart = "RAN")
crossOut <- crossover(selec6best, 3, uplimit = 300, crossPart = "EQU")
## MUTATION
## Variable Mutation Rate is activated if more than 2 individuals represent
## the current best solution.
mut <- mutation(a = crossOut, p = 0.3, NULL)
## TRIMTON
## After Crossover and Mutation, the amount of turbines in a windpark change and have to be
## corrected to the required amount of turbines.
mut1 <- trimton(
mut = mut, nturb = 10, allparks = allparks, nGrids = AmountGrids,
trimForce = FALSE
)
colSums(mut)
colSums(mut1)
Find potentially influencing turbines
Description
Find all turbines that could potentially influence another turbine and save them to a list.
Usage
turbine_influences(t, wnkl, dist, polYgon, dirct, plotAngles = FALSE)
Arguments
t |
A data.frame of the current individual with X and Y coordinates |
wnkl |
The angle from which wake influences are considered to be negligible |
dist |
A numeric value indicating the distance, after which the wake effects are considered to be eliminated. |
polYgon |
A shapefile representing the considered area |
dirct |
A numeric value indicating the current wind direction |
plotAngles |
A logical variable, which is used to plot the distances and
angles. Default is |
Value
Returns a list of all individuals of the current generation which could potentially influence other turbines. List includes the relevant coordinates, the distances and angles in between and assigns the Point ID.
See Also
Other Wind Energy Calculation Functions:
barometric_height()
,
calculate_energy()
,
circle_intersection()
,
get_dist_angles()
Examples
## Exemplary input Polygon with 2km x 2km:
library(sf)
Polygon1 <- sf::st_as_sf(sf::st_sfc(
sf::st_polygon(list(cbind(
c(0, 0, 2000, 2000, 0),
c(0, 2000, 2000, 0, 0)
))),
crs = 3035
))
t <- st_coordinates(st_sample(Polygon1, 10))
t <- cbind(t, "Z" = 1)
wnkl <- 20
dist <- 100000
dirct <- 0
res <- turbine_influences(t, wnkl, dist, Polygon1, dirct, plotAngles = TRUE)
Transform Winddata
Description
Helper Function, which transforms winddata to an acceptable format
Usage
windata_format(df)
Arguments
df |
The wind data with speeds, direction and optionally a probability column. If not assigned, it will be calculated |
Value
A list of windspeed and probabilities
See Also
Other Helper Functions:
get_grids()
,
grid_area()
,
hexa_area()
,
isSpatial()
,
permutations()
,
readinteger()
,
readintegerSel()
,
splitAt()
Examples
wind_df <- data.frame(
ws = c(12, 30, 45),
wd = c(0, 90, 150),
probab = 30:32
)
windata_format(wind_df)
wind_df <- data.frame(
speed = c(12, 30, 45),
direction = c(90, 90, 150),
probab = c(10, 20, 60)
)
windata_format(wind_df)
wind_df <- data.frame(
speed = c(12, 30, 45),
direction = c(400, 90, 150)
)
windata_format(wind_df)
